14.4.8.5 Configuring Clock Synchronization
In this scenario, network-wide clock synchronization is implemented through synchronous
Ethernet clocks.
Prerequisites
l The clock daughter board CKMC/CKMD of the SCU board must be in position.
l The ethernet upstream board must be GICK/GSCA (GE port) or X2CS (10GE port)/SPUF
(need an independent service board slot).
l The upstream MAN PSN of the OLT must feature the capability of Ethernet
synchronization.
Context
The clock synchronization scheme of a small-cell base station can be synchronous Ethernet
(frequency synchronization) or IEEE 1588v2 (time synchronization). This topic uses the
synchronous Ethernet as an example to describe how to configure clock synchronization. For
IEEE 1588v2 time synchronization configurations, see 14.3.6 Configuring 1588v2 Clock
Synchronization.
Data Plan
Configuration
Item
Data
GIU upstream board Port: 0/19/0
DSLAM (MA5616)
port
Upstream port: 0/0/1
UNI interface: 0/3/0
ONU Port Upstream port: 0/0/0
UNI interface: 0/1/0
Procedure
l Configure the OLT-side clock.
1. Configure a system clock source.
Use the Ethernet line clock input from GIU port 0/19/0 as the system clock. Set the
index of the system clock to 0 and priority to 0 (highest priority).
huawei(config)#clock source 0 0/19/0
huawei(config)#clock priority system 0
2. Query the configurations and status of the system clock source.
Run the display clock source system command to query the configurations and status
of the system clock source. Ensure that the configurations of the system clock source
are correct and the status of the system clock source is Normal.
huawei(config)#display clock source system
-------------------------------------------------------------------------
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1500
