Service Board GPMD: 0/3
SPU Board SPUF: 0/4, 0/5
16.4.1 Home Service Networking
In home service networking, an MA5633 connects to cable modems (CMs) at user homes
through radio frequency (RF) ports and provides home services for users, including the cable
TV (CATV) service, Internet access service, VoD service, broadband TV (BTV) service, and
PacketCable service. This section describes how to configure the optical line terminal (OLT)
and the MA5633 to provision the home services.
NOTE
Configuration procedures are the same for IPv6 and IPv4 networks except in "Configure Dynamic Host
Configuration Protocol (DHCP) relay" and "Configure a route". In addition, IPv6 does not support the
function of configuring PacketCable dynamic voice services.
16.4.1.1 Service Requirements and Usage Scenario
Service Requirements
Users require the provisioning of the TV service, Internet access service, VoD service,
broadband TV (BTV) service, and VoIP service. The TV service can be provisioned immediately
after the distributed cable modem termination system (D-CMTS) hardware is connected. This
section only describes how to configure the Internet access service, VoD service, BTV service,
and VoIP service.
Usage Scenario
As shown in Figure 16-9, MA5633 is deployed on an optical node and cable modems (CMs)
are deployed at user homes. The CMs connect to radio frequency (RF) ports on the MA5633
through cables.
l Port 1 on CM 1 connects to a PC for the Internet access service, port 2 connects to a phone
set for the VoIP service, and the distributor connects to the STB for the VoD service. CM
1 supports embedded media terminal adapter (EMTA) functions and the voice users of CM
1 use PacketCable 1.x.
l CM 2 does not support EMTA functions and needs to connect to a media terminal adapter
(MTA). The voice users of CM 2 use PacketCable Multimedia.
l Users access the Internet through Dynamic Host Configuration Protocol (DHCP) dialup.
l The IP addresses of the CM, STB, PC, and MTA are assigned by the DHCP server and in
different network segments.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1733
