Remote
Service
Verificati
on
Method
Function Remarks
Call
emulation
An ONU emulates a call to check
whether the voice service
configurations are correct. The call
emulation function can also be used to
locate faults when a voice service is
faulty.
l An ONU can emulate a caller or
callee in an emulation test. A
functional phone is required in the
central office where the
acceptance personnel is.
l An ONU can emulate the caller
and callee simultaneously in an
emulation test. No phone is
required in the test.
l An ONU supports a maximum of
one call emulation.
Data Plan
Item Data Remarks
PPPoE
dialup
emulation
parameter
Service flow ID: 101
Emulation timer: 10s
The user name, password, and
authentication mode required by the
emulation test must be consistent with
those configured on the BRAS.
Call
emulation
parameter
Caller port: 0/3/0
Called port: 0/3/23
Called number: 83110024
When an ONU simultaneously
emulates the caller and the callee in an
emulation test, retain the parameter
settings as default. To query default
values, run the display pots
emulational configuration
command.
Procedure
l Verify the Internet access service using PPPoE dialup emulation.
1. Start an emulation test by running the simulate dhcp start command.
huawei(config)#pppoe simulate start
Command:
pppoe simulate start
Service-port(index<0-999>):101
User Name(length<1,65>):user0
User Password(length<0,16>):*******
Authentication Mode:
1. Chap 2. Pap [default 1]:1
Overtime Time(5-60s)[default 5]:10
2. Query the emulation test information by running the display pppoe simulate info
command.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
880
