4-10 FI SYSTEM DIAGNOSIS
COMPENSATION OF INJECTION TIME (VOLUME)
The following different signals are output from the respective sensors for compensation of the fuel injection
time (volume).
INJECTION STOP CONTROL
SIGNAL DESCRIPTION
ENGINE COOLANT TEMPERATURE SEN-
SOR SIGNAL
When engine coolant temperature is low, injection time (vol-
ume) is increased.
INTAKE AIR TEMPERATURE SENSOR
SIGNAL
When intake air temperature is low, injection time (volume)
is increased.
BATTERY VOLTAGE SIGNAL ECM operates on the battery voltage and at the same time,
it monitors the voltage signal for compensation of the fuel
injection time (volume). A longer injection time is needed to
adjust injection volume in the case of low voltage.
ENGINE RPM SIGNAL At high speed, the injection time (volume) is increased.
ACCELERATION SIGNAL/
DECELERATION SIGNAL
During acceleration, the fuel injection time (volume) is
increased in accordance with the throttle opening speed and
engine rpm. During deceleration, the fuel injection time (vol-
ume) is decreased.
SIGNAL DESCRIPTION
TIP OVER SENSOR SIGNAL
(FUEL SHUT-OFF)
When the motorcycle tips over, the tip over sensor sends a
signal to the ECM. Then, this signal cuts OFF current sup-
plied to the fuel pump, fuel injector and ignition coil.
OVER-REV. LIMITER SIGNAL The fuel injectors stop operation when engine rpm reaches
rev. limit rpm.
