ELECTRICAL
Unit: mm (in)
ITEM SPECIFICATION NOTE
Firing order 1.2
Spark plug
Type
NGK: CR8E
DENSO: U24ESR-N
Gap
0.7 – 0.8 mm
(0.028 – 0.031 in)
Spark performance Over 8 mm (0.3 in) at 1 atm.
CKP sensor resistance 130 – 240 Ω W – G
Ignition coil resistance
Primary * 1 – 5 Ω
Terminal –
Terminal
Secondary * 25 – 40 kΩ
Plug cap – Plug
cap
CKP sensor peak voltage 3.7 V and more When cranking
Ignition coil primary peak voltage 150 V and more
Generator coil resistance 0.2 – 0.7 Ω
Generator Max. output Approx. 375 W at 5 000 r/min
Generator no-load voltage
(When cold)
60 V (AC) and more at 5 000 r/min.
Regulated voltage 14.0 – 15.5 V at 5 000 r/min.
Starter relay resistance 3 – 6 Ω
Battery Type designa-
tion
YTX12-BS
Capacity 12 V 36.0 kC (10 Ah)/10 HR
Fuse size
Headlight
HI 15 A
LO 15 A
Fuel 10 A
Ignition 10 A
Fan motor 15 A
Signal 15 A
Main 30 A
DL650K7/AK7 (’07-MODEL) 13-149
