CHASSIS 7-61
#
CALIPER REMOVAL AND DISASSEMBLY
• Drain the brake fluid. ("7-60)
• Remove the brake pads. ("7-59)
• Disconnect the brake hoses by removing the brake hose
union bolts.
NOTE:
Place a rag underneath the union bolt on the brake caliper to
catch any spilt brake fluid.
• Remove the brake calipers by removing the caliper mounting
bolts.
#
)
• Remove the caliper holder

1.
• Remove the pad spring

2.
* Never reuse the brake fluid left over from previous
servicing and which has been stored for long peri-
ods of time.
* Bleed air from the brake system. ("2-25)
Do not reuse the brake fluid left over from previous
servicing and stored for long periods of time.
Brake fluid, if it leaks, will interfere with safe running
and discolor painted surfaces. Check the brake hose
and hose joints for cracks and fluid leakage.
