SERVICING INFORMATION 9-41
FI SYSTEM PARTS
ITEM N·m kgf-m lb-ft
Exhaust pipe bolt/nut 23 2.3 16.5
Muffler mounting bolt/nut 23 2.3 16.5
Oil pipe stopper screw 8 0.8 6.0
Engine sprocket nut 145 14.5 105
Engine mounting bolt/nut 55 5.5 40.0
Engine mounting nut
[Center] 93 9.3 67.5
Engine mounting thrust adjuster 12 1.2 8.5
Engine mounting thrust adjuster lock-nut 45 4.5 32.5
Engine mounting bracket bolt 35 3.5 25.5
Engine mounting pinch bolt 25 2.5 18.0
Cooling fan thermo-switch 17 1.7 12.5
ECT sensor 19 1.9 13.5
Fuel pump mounting bolt 10 1.0 7.0
Fuel delivery pipe mounting screw 5.0 0.5 3.7
Cooling fan/horn mounting bolt 8 0.8 6.0
Thermostat case bolt 10 1.0 7.0
Oil cooler mounting bolt 10 1.0 7.0
Oil cooler hose union bolt 23 2.3 16.5
ITEM N·m kgf-m lb-ft
TP sensor mounting screw 3.5 0.35 2.5
STP sensor mounting screw 2.0 0.2 1.5
ECT sensor 19 1.9 13.5
IAT sensor 18 1.8 13.0
