13-76 DL650K7/AK7 (’07-MODEL)
ABS COUPLER CONNECTION DIAGRAM
SPEEDOMETER
FUSE BOX
ABS MOTOR FUSE
FRONT WHEEL SPEED SENSOR
IGNITION SWITCH
MODE SELECT SWITCH
REAR WHEEL SPEED SENSOR
ABS CONTROL UNIT
ABS VALVE FUSE
WIRE HARNESS
(Wire harness No.2) (Wire harness No.1)
(Harness side)
10A
15A
15A
10A 15A
15A
10A
15A
O
B/W
O/R
O
O
Gr
O/G
Br R
O/Y
Br
B/R
Y/B
B
Lg
R/W
B/W
Bl
B/G
Y
Bl/B O/G
Br/B
P/W
G/Y
O/R
Bl/BB
Br/B
Lg
P/W
B/W
R/W
Y
Y/B
Br
Bl
G/Y
O/R
B/Bl
B/G
O/G
Bl/B
Br/B
Lg
P/W
B/W
R/W
Y
Y/B
Br
B
Bl
G/Y
O/R
W
B/G
O/G
WBW B B/R W/RB/Y W/Y
25A40A
SPARE 40A
SPARE 25A
B
O
R
R/B
B/W
B/R
W/Y
Gr/R
Bl
W/R
O/Y
B/Y
HEAD-HI
IGNITION
SIGNAL
HEAD-LO
FUEL
FAN
SPARE SPARE
WIRE COLORS
B Bl Br
O/G O/R O/Y P/W R/B R/W W/R W/Y Y/B
: Black : Blue : Brown
: Orange with Green tracer : Orange with Red tracer : Orange with Yellow tracer : Pink with White tracer : Red with Black tracer : Red with White tracer : White with Red tracer : White with Yellow tracer : Yellow with Black tracer
Gr Lg O R W Y
: Gray : Light green : Orange : Red : White : Yellow
B/Bl B/G B/R B/W B/Y Bl/B Br/B G/Y Gr/R
: Black with Blue tracer : Black with Green tracer : Black with Red tracer : Black with White tracer : Black with Yellow tracer : Blue with Black tracer : Brown with Black tracer : Green with Yellow tracer : Gray with Red tracer
SDS
O/G
Gr/R
W/RB/W
