9-40 SERVICING INFORMATION
TIGHTENING TORQUE
ENGINE
ITEM N·m kgf-m lb-ft
Cylinder head cover bolt 14 1.4 10.0
Spark plug 11 1.1 8.0
Camshaft journal holder bolt 10 1.0 7.0
Cam chain tension adjuster cap bolt 8 0.8 5.7
Cam chain tension adjuster mounting bolt 10 1.0 7.0
Cylinder head bolt [M: 10] Initial 25 2.5 18.0
Final 42 4.2 30.5
Water drain bolt 13 1.3 9.5
Clutch sleeve hub nut 50 5.0 36.0
Clutch spring set bolt 10 1.0 7.0
Oil plate bolt 10 1.0 7.0
Oil pressure regulator 27 2.7 19.5
Oil strainer plate bolt 10 1.0 7.0
Primary drive gear bolt 70 7.0 50.5
Generator cover plug 10 1.0 7.0
Valve timing inspection plug 23 2.3 16.3
Generator rotor bolt 120 12.0 87
Starter clutch bolt 25 2.5 18.0
Generator stator set bolt 11 1.1 8.0
CKP sensor set bolt 6.5 0.65 4.7
Gearshift cam stopper bolt 10 1.0 7.0
Gearshift cam stopper plate bolt 13 1.3 9.5
Gearshift arm stopper bolt 19 1.9 13.5
Oil pressure switch 13 1.3 9.5
Crankcase bolt
[M: 6]
11 1.1 8.0
[M: 8]
26 2.6 19.0
Generator cover bolt
[M: 6]
10 1.0 7.0
Oil gallery plug
[M: 8]
18 1.8 13.0
Oil drain plug 21 2.1 15.0
Piston cooling oil jet bolt 10 1.0 7.0
Conrod bearing cap bolt
Initial
21 2.1 15.0
Final
After tightenig the bolts to the above torque,
tighten them 1/4 of a turn (90 °).
