SERVICING INFORMATION 9-33
SIDE-STAND SET-UP
BRAKE PEDAL/FOOTREST SET-UP
!
ITEM N·m
kgf-m
lb-ft

A 40 4.0 29.0

B 50 5.0 36.0

C 100 10.0 72.5

1 Pin

3 Footrest

2 E-ring

4 Brake light switch
A – A
A
A
