FI SYSTEM DIAGNOSIS 4-11
FI SYSTEM PARTS LOCATION

A Speedometer

F Fuel injector, No.1

B CKP sensor

G Fuel injector, No.2

C TP sensor

H Ignition coil, No.1

D Gear position sensor

I STVA

E STP sensor

J TO sensor
ECM
A
I
F G C
E
J
H
B
D
