9-30 SERVICING INFORMATION
PAIR (AIR SUPPLY) SYSTEM HOSE ROUTING
*1

1
Matching mark (White)
*1
Pass the PAIR hose between the cylinder head
cover and intake pipe.

2 Matching mark (Yellow)
