COOLING AND LUBRICATION SYSTEM 6-7
RADIATOR CAP
INSPECTION
• Remove the radiator cap. (#6-3)
• Fit the cap

1 to the radiator cap tester

2.
• Build up pressure slowly by operating the tester. Make sure
that the pressure build-up stops at 95 – 125 kPa (0.95 – 1.25
kgf/cm², 13.5 – 17.8 psi) and that, with the tester held stand-
still, the cap is capable of holding that pressure for at least 10
seconds.
• Replace the cap if it is found not to satisfy above require-
ments.
% Radiator cap valve opening pressure
Standard: 95 – 125 kPa
(0.95 – 1.25 kgf/cm², 13.5 – 17.8 psi)
WATER HOSE
INSPECTION
• Remove the cowling. (#7-5)
Any water hose found in a cracked condition or flattened or
water leaked must be replaced.
Any leakage from the connecting section should be corrected by
proper tightening.
