WIRE HARNESS, HOSE ROUTING AND SENSOR INSTALLATION
WIRE HARNESS ROUTING
*1 Clamp end should face upward. *3 Pass through the harness under the cowling boss.
*2 Cut the tip of clamp after clamp. *4
Triangle mark of each spark plug cap must be brought
to the exhaust side.
Wiring harness
IG coil coupler
Clamp
Starter motor
Wire harness
Stop lamp switch
ABS sensor (DL650A)
Fuel pump coupler
Taping clamp
Clamp
Rectifier
(Breather hose)
IAP sensor
*1
Solenoid
Clamp
ISC valve coupler
Speed sensor
*2
Wire harness
Handle switch L & R
*3
Clutch cable
Handle
switch (L)
Throttle cable
Taping clamp
Fuse
DL650A
only
Joint coupler
#1 Ignition
coil
High-
tension
cord
Water hose
Inside
Clamp
Clamp
Clamp
Side-stand switch
Wire harness
Side-stand switch
GP switch
Side-stand switch
GP switch
*4
12-128 DL650K7/AK7 (’07-MODEL)
