SERVICING INFORMATION 9-31
SEAT LOCK CABLE ROUTING
HEAD LAMP SET-UP

1 Seat lock cable
VIEW OF LEFT
VIEW OF TOP
*1 *2
*3
*1
Adhere cushion along the ridge line of lens.
*3
Right and left cushions shall be attached sym-
metrically.
*2 Start to adhere cushion from the corner of lens.
