2-6 PERIODIC MAINTENANCE
NOTE:
When cleaning the air cleaner element, drain water from the air
cleaner by removing the drain plug.
SPARK PLUG
NO.1 (FRONT) SPARK PLUG REMOVAL
• Remove the cowling. (!7-5).
• Remove the radiator mounting bolt

1.
• Move the radiator lower side to forward.
• Remove the spark plug cap

2.
NOTE:
Be careful not to damage the radiator fins.
#
• Remove the spark plug with the special tool.
$09930-10121: Spark plug socket wrench set
Inspect every 6 000 km (4 000 miles, 12 months) and
replace every 12 000 km (7 500 miles, 24 months).
The hot radiator and the hot engine can burn you. Wait
until the radiator and the engine are cool enough to
touch.
