– 7 –
TRANSMISSION + DRIVE CHAIN
Unit: mm (in) Except ratio
ITEM STANDARD LIMIT
Primary reduction ratio 2.088 (71/34) ----
Final reduction ratio 3.133 (47/15) ----
Gear ratios Low 2.461 (32/13) ----
2nd 1.777 (32/18) ----
3rd 1.380 (29/21) ----
4th 1.125 (27/24) ----
5th 0.961 (25/26) ----
Top 0.851 (23/27) ----
Shift fork to groove clearance 0.1 – 0.3
(0.004 – 0.012)
0.50
(0.020)
Shift fork groove width 5.5 – 5.6
(0.217 – 0.220)
----
Shift fork thickness 5.3 – 5.4
(0.209 – 0.213)
----
Drive chain
Type DID525V8
----
----
Links 116 links ----
20-pitch
length
----
319.4
(12.57)
Drive chain slack (on side-stand) 20 – 30
(0.79 – 1.18)
----
Gearshift lever height 25
(0.98)
----
DL650K6 ('06 MODEL) 12- 7
