SERVICING INFORMATION 9-29
FUEL TANK INSTALLATION
1 ~ 2 mm
(0.04 ~ 0.08 in)
27 mm
(1.06 in)
*1

1
Fuel tank center shield
*1
Align the front end of fuel tank center shield with
this position.

2 Fuel tank side cushion
