ABS UNIT SYSTEM DIAGRAM
Pump motor
Motor
relay
Valve
relay
Rear wheel
speed sensor
Front wheel
speed sensor
ABS
indicator
light
25
11
16
5
7
19
4132
12
18
4321
15 14 13 12 11 10 9 8 7 6 5
26 25 24 23 22 21 20 19 18 17 16
1
Front inlet valve
2
Front outlet valve
3
Rear inlet valve
4
Rear outlet valve
Fuse
40 A
Fuse
25 A
Fuse
10 A
SDS
Mode select
coupler
Ignition
Battery
13-78 DL650K7/AK7 (’07-MODEL)
