9-28 SERVICING INFORMATION
FUEL TANK DRAIN HOSE ROUTING
*1
*3
*2
*1
Route fuel tank drain hose so that its curve faces
forward.
*3
Make sure to position the clamp in the specified
direction.
*2
Route fuel tank drain hose to come inside (left
side) gear position sensor wiring harness.
