CHASSIS
Front suspension ................................................. Telescopic, coil spring, oil damped
Rear suspension.................................................. Link type, coil spring, oil damped
Front fork stroke................................................... 150 mm (5.9 in)
Rear wheel travel................................................. 150 mm (5.9 in)
Caster .................................................................. 26°
Trail...................................................................... 110 mm (4.33 in)
Steering angle...................................................... 40° (right & left)
Turning radius...................................................... 2.6 m (8.5 ft)
Front brake........................................................... Disc brake, twin
Rear brake ........................................................... Disc brake
Front tire size ....................................................... 110/80 R19 M/C 59H, tubeless
Rear tire size........................................................ 150/70 R17 M/C 69H, tubeless
ELECTRICAL
Ignition type.......................................................... Electronic ignition (Transistorized)
Ignition timing....................................................... 4° B.T.D.C. at 1 300 r/min
Spark plug............................................................ NGK CR8E or DENSO U24ESR-N
Battery.................................................................. 12 V 36.0 kC (10 Ah)/10 HR
Generator............................................................. Three-phase A.C. generator
Main fuse ............................................................. 30 A
Fuse..................................................................... 15/15/10/10/15/15 A
Headlight.............................................................. 12 V 60/55 W × 2 (H4)
Position/Parking light ........................................... 12 V 5 W × 2 ..............Except for E-03, 24, 28,33
Brake light/Taillight............................................... 12 V 21/5 W × 2
Licence plate light ................................................ 12 V 5 W
Turn signal light.................................................... 12 V 21 W
Speedometer light................................................ LED
Tachometer light .................................................. LED
Turn signal indicator light..................................... LED
Neutral indicator light ........................................... LED
High beam indicator light ..................................... LED
Oil pressure/Coolant temperature/
Fuel injection indicator light.................................. LED
CAPACITIES
Fuel tank, including reserve................................. 22.0 L (5.8/4.8 US/lmp gal)
Engine oil, oil change ......................................... 2 300 ml (2.4/2.0 US/lmp qt)
with filter change............................... 2 700 ml (2.9/2.4 US/lmp qt)
overhaul............................................ 3 100 ml (3.3/2.7 US/lmp qt)
Engine coolant ..................................................... 1.9 L (2.0/1.7 US/lmp qt)
These specifications are subject to change without notice.
13- 8 DL650K7/AK7 (’07-MODEL)
