ELECTRICAL SYSTEM 8-29
COMBINATION METER
REMOVAL AND DISASSEMBLY
• Disconnect the battery

- lead wire.
• Remove the combination meter panel. (!7-6).
• Remove the combination meter

1.
"
• Disassemble the combination meter as follows.
"
When disconnecting and connecting the combination
meter coupler, make sure to turn OFF the ignition
switch, or electronic parts may get damaged.
Do not attempt to disassemble the combination meter
unit.

1 Combination meter cover

2 Combination meter unit
