7-26 CHASSIS
STEERING AND HANDLEBAR
CONSTRUCTION

1 Handlebars

0 Spacer

2 Steering stem upper bracket

A Washer

3 Dust seal

B Expander !

4 Bearing upper

A Handlebar clamp bolt ITEM N·m
kgf-m lb-ft

5 Bearing lower

B Steering stem head nut

A 23 2.3 16.5

6 Steering stem lower bracket

C Front fork upper clamp bolt

B 90 9.0 65.0

7 Steering stem nut

D Steering stem lock-nut

C 23 2.3 16.5

8 Handlebar balancer

E Front fork lower clamp bolt

D 80 8.0 58.0

9 Expander

E 23 2.3 16.5
