DL650K7/AK7 (’07-MODEL) 13-91
DTC DELETING AND ABS OPERATION
CHECK
DTC DELETING
• Connect the special tool to the mode select coupler (O – B/W)
and output the DTCs.
\ 09930-82710: Mode select switch
• While the DTCs are being output, set the special tool to OFF.

• In the DTC deletion mode, switch the ABS test switch from
OFF to ON 3 times, each time leaving it at ON for more than 1
second.
NOTE:
After deleting DTC with the mode select switch in ON position,
the system resumes the self-diagnosis mode again and outputs
the DTC.
The DTC deletion mode starts 12.5 seconds after the
switch is set to OFF.
