CHASSIS 7-69
)
#
BRAKE PAD REPLACEMENT
• Remove the plug

1.
• Loosen the pad mounting pin

2.
• Remove the caliper bracket bolt

3.
#
• Remove the pad mounting pin and brake pads with the rear
caliper pivoted up.
• Clean up the caliper especially around the caliper pistons.
* This brake system is filled with an ethylene glycol-based DOT 4 brake fluid. Do not use or mix
different types of fluid such as silicone-based or petroleum-based.
* Do not use any brake fluid taken from old, used or unsealed containers. Never reuse brake
fluid left over from the last servicing or stored for long periods.
* When storing the brake fluid, seal the container completely and keep away from children.
* When replenishing brake fluid, take care not to get dust into fluid.
* When washing brake components, use fresh brake fluid. Never use cleaning solvent.
* A contaminated brake disc or brake pad reduces braking performance. Discard contaminated
pads and clean the disc with high quality brake cleaner or neutral detergent.
Handle brake fluid with care: the fluid reacts chemically with paint, plastics, rubber materials
etc. and will damage them severly.
* Do not operate the brake pedal while dismounting
the pads.
* Replace the brake pads as a set, otherwise braking
performance will be adversely affected.
