– 2 –
SPECIFICATIONS
DIMENSIONS AND DRY MASS
Overall length ...................................................................................... 2 290 mm (90.2 in)
Overall width........................................................................................ 840 mm (33.1 in)
Overall height ...................................................................................... 1 390 mm (54.7 in)........... Low windshield position (STD)
1 420 mm (55.9 in)...........Middle windshield position
1 450 mm (57.1 in)........... High windshield position
Wheelbase .......................................................................................... 1 540 mm (60.6 in)
Ground clearance................................................................................ 165 mm (6.5 in)
Seat height.......................................................................................... 820 mm (32.3 in)
Dry mass............................................................................................. 190 kg (418 lbs)
ENGINE
Type..................................................................................................... 4-stroke, liquid-cooled, DOHC, 90 ° -degree V-twin
Number of cylinders ............................................................................ 2
Bore..................................................................................................... 81.0 mm (3.189 in)
Stroke.................................................................................................. 62.6 mm (2.465 in)
Displacement ...................................................................................... 645 cm
3
(39.4 cu. in)
Compression ratio............................................................................... 11.5 : 1
Carburetion.......................................................................................... Fuel injection
Air cleaner ........................................................................................... Non-woven fabric element
Starter system..................................................................................... Electric
Lubrication system .............................................................................. Wet sump
Idle speed............................................................................................ 1 300 ± 100 r/min
DRIVE TRAIN
Clutch.................................................................................................. Wet multi-plate type
Transmission ....................................................................................... 6-speed constant mesh
Gearshift pattern ................................................................................. 1-down, 5-up
Primary reduction ratio........................................................................ 2.088 (71/34)
Final reduction ratio............................................................................. 3.133 (47/15)
Gear ratios, Low.................................................................................. 2.461 (32/13)
2nd................................................................................... 1.777 (32/18)
3rd ................................................................................... 1.380 (29/21)
4th.................................................................................... 1.125 (27/24)
5th.................................................................................... 0.961 (25/26)
Top................................................................................... 0.851 (23/27)
Drive chain .......................................................................................... DID525V8, 116 links
CHASSIS
Front suspension................................................................................. Telescopic, coil spring, oil damped
Rear suspension ................................................................................. Link type, coil spring, oil damped
Front fork stroke .................................................................................. 150 mm (5.9 in)
Rear wheel travel................................................................................. 150 mm (5.9 in)
Caster.................................................................................................. 26 °
Trail...................................................................................................... 110 mm (4.33 in)
Steering angle..................................................................................... 40 ° (right & left)
Turning radius...................................................................................... 2.6 m (8.5 ft)
Front brake .......................................................................................... Disc brake, twin
Rear brake........................................................................................... Disc brake
Front tire size....................................................................................... 110/80 R19 M/C 59H, tubeless
Rear tire size....................................................................................... 150/70 R17 M/C 69H, tubeless
ELECTRICAL
Ignition type......................................................................................... Electronic ignition (Transistorized)
Ignition timing. ..................................................................................... 4 ° B.T.D.C. at 1 300 r/min
Spark plug........................................................................................... NGK CR8E or DENSO U24ESR-N
Battery................................................................................................. 12 V 36.0 kC (10 Ah) /10 HR
Generator............................................................................................ Three-phase A.C. generator
Main fuse............................................................................................. 30 A
Fuse .................................................................................................... 15/15/10/10/15/15 A
Headlight............................................................................................. 12 V 60/55 W x 2 (H4)
Position/parking light ........................................................................... 12 V 5 W x 2 ......Except E-03, 24, 28, 33
Brake light/Taillight............................................................................... 12 V 21/5 W x 2
License plate light ............................................................................... 12 V 5 W
Turn signal light ................................................................................... 12 V 21 W
Speedometer light............................................................................... LED
Turn signal indicator light..................................................................... LED
Neutral indicator light........................................................................... LED
High beam indicator light..................................................................... LED
Oil pressure/Coolant temperature/Fuel injection warning light............ LED
CAPACITIES
Fuel tank, including reserve ............................................................... 22 L (5.8/4.8 US/Imp gal)
Engine oil, oil change ......................................................................... 2 300 ml (2.4/2.0 US/Imp qt)
with filter change............................................................... 2 700 ml (2.9/2.4 US/Imp qt)
overhaul. ........................................................................... 3 100 ml (3.3/2.7 US/Imp qt)
Coolant................................................................................................ 1.9 L (2.0/1.7 US/Imp qt)
DL650K5SB.fmPage2Wednesday,October20,20044:30PM
DL650K5 ('05 MODEL)11- 2
