7-62 CHASSIS
• Place a rag over the pistons to prevent them from popping out
and then force out the pistons using compressed air.
#
• Remove the dust seals

3 and piston seals

4.
#
CALIPER INSPECTION
BRAKE CALIPER
Inspect the brake caliper cylinder wall for nicks, scratches and
other damage. If any damage is found, replace the caliper with a
new one.
BRAKE CALIPER PISTON
Inspect the brake caliper piston surface for any scratches and
other damage. If any damage is found, replace the caliper pis-
tons with the new ones.
CALIPER HOLDER
Inspect the caliper holder for damage. If any damage is found,
replace it with a new one.
Do not use high pressure air to prevent piston dam-
age.
Do not reuse the removed dust seals and piston seals
to prevent fluid leakage.
