7-20 CHASSIS
INSPECTION
INNER AND OUTER TUBES
Inspect the inner tube outer surface and the outer tube inner sur-
face for scratches. If any defects are found, replace them with
the new ones.
FORK SPRING
Measure the fork spring free length. If it is shorter than the ser-
vice limit, replace it with a new one.
% Front fork spring free length
Service limit: 435 mm (17.1 in)
CYLINDER
Inspect the cylinder and cylinder ring

1 for damage. If any
defect is found, replace them with a new one.
