7-82 CHASSIS
• In this condition, check the “rim line”
A cast on the tire side
walls. The line must be equidistant from the wheel rim all
around. If the distance between the rim line
A and wheel rim
varies, this indicates that the bead is not properly seated. If
this is the case, deflate the tire completely and unseat the
bead for both sides. Coat the bead with lubricant and fit the
tire again.
• When the bead has been fitted properly, adjust the pressure
to specification.
• As necessary, adjust the tire balance.
#
% Tire pressure
Solo riding: Front: 225 kPa (2.25 kgf/cm², 33 psi)
Rear : 250 kPa (2.50 kgf/cm², 36 psi)
Dual riding: Front: 225 kPa (2.25 kgf/cm², 33 psi)
Rear : 280 kPa (2.80 kgf/cm², 41 psi)
Do not run with a repaired tire at a high speed.
