7-4 CHASSIS
REMOVAL
SEAT
• Remove the seat with the ignition key
1.
FUEL TANK SIDE COVER
• Remove the seat. ("7-4)
• Remove the fuel tank side covers
1.
NOTE:
“
✩
” indicates hook location.
CARRIER
• Remove the seat. ("7-4)
• Remove the carrier
1.
