BATTERY PROTECTOR INSTALLATION
*1
Align the top of protector with the upper surface
of the battery holder.
FWD
45 mm (1.77 in)
3.12 mm (0.12 in)
6.2 mm (0.24 in)
20 mm (0.79 in)
*1
*1
13-140 DL650K7/AK7 (’07-MODEL)
