ABS COMPONENTS
ABS COMPONENTS LOCATION
1 ABS indicator light 4 ABS control unit/HU
2 Front wheel speed sensor rotor 5 Rear wheel speed sensor rotor
3 Front wheel speed sensor 6 Rear wheel speed sensor
DL650K7/AK7 (’07-MODEL) 13-75
