Xerox VersaLink B7025 Service Manual

April 2017
2-111
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
016-233, 016-234, 016-235
Status Indicator RAPs
Launch Issue
016-233 SW Option Fail (USB Host Not Installed) RAP
016-233 Any one of the SW optional functions cannot be used because the USB host has a
failure or is not installed.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Reload the software, GP 4.
3. Install a new ESS PWB, PL 3.10 Item 6.
016-234, 016-235 XCP Error RAP
016-234 Lack of memory causes the XCP to stop.
016-235 Another internal error causes the XCP function to stop.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Initialise the hard disk. Refer to dC355 Hard Disk Diagnostics.
