Xerox VersaLink B7025 Service Manual

April 2017
2-76
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-903, 012-903A
Launch Issue
Status Indicator RAPs
012-903 Compiler Exit Sensor On Entry RAP
012-903 The compiler exit sensor was detected on.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-903A Compiler Exit Sensor On RAP.
• Office finisher LX installed, 012-903B Compiler Exit Sensor On RAP.
012-903A Compiler Exit Sensor On RAP
BSD-ON: BSD 12.3 Integrated Office Finisher Transportation
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-903 Compiler Exit Sensor On
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check the power supply voltage at the customer site for a drop.
• Check the compiler exit sensor, PL 12.12 Item 16 is correctly installed and free from for-
eign objects and that the actuator is not binding.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 code 012-150. Actuate the compiler exit sensor. The display changes.
YN
Check the connections of P/J8709 and P/J8728. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8709 and P/J8728. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8709 pin 3 (+) and ground (-). The
voltage is approximately +5VDC.
YN
Check the +5VDC circuit. Refer to the Wiring Diagrams.
Measure the voltage between the finisher PWB P/J8709 pin 2 (+) and ground (-). Actuate
the compiler exit sensor.
The voltage changes.
YN
Install a new compiler exit sensor, PL 12.12 Item 16.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
