Xerox VersaLink B7025 Service Manual

April 2017
2-74
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
012-302, 012-302A
Launch Issue
Status Indicator RAPs
012-302 Front Cover Interlock Open Entry RAP
012-302 The front cover interlock open was detected.
Procedure
Go to the relevant procedure:
• Integrated office finisher installed, 012-302A Front Cover Interlock Open RAP.
• Office finisher LX installed, 012-302B Front Cover Interlock Open RAP.
012-302A Front Cover Interlock Open RAP
BSD-ON: BSD 12.1 Integrated Office Finisher DC Power and Interlock Switching
Initial Actions
NOTE: Ensure the correct RAP is performed, refer to the 012-302 Front Cover Interlock Open
Entry RAP.
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
• Check that the front cover can be opened and closed.
• Check that the finisher front interlock switch, PL 12.14 Item 12 is correctly installed and
undamaged.
• Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330 code 012-302. Open, then close the front cover to actuate the finisher front inter-
lock switch. The display changes.
YN
Check the connections of P/J8702 and P/J8733. The connectors are good.
YN
Secure the connections.
Check for an open or short circuit between P/J8702 and P/J8733. The wiring is good.
YN
Repair the open or short circuit.
Measure the voltage between the finisher PWB P/J8702 pin 4 (+) and ground (-). Open,
then close the front cover to actuate the finisher front interlock switch.
The voltage
changes.
YN
Install a new finisher front interlock switch, PL 12.14 Item 12.
Check the wires and connectors for an intermittent open or short circuit. If the fault per-
sists, install a new finisher PWB, PL 12.14 Item 1.
Measure the voltage between the finisher PWB P/J8702 pin 1 (+) and (-). The voltage is
approximately +24VDC.
YN
Check the +24VDC circuit. Refer to the Wiring Diagrams.
Check the wires and connectors for an intermittent open or short circuit. If the fault persists,
install a new finisher PWB, PL 12.14 Item 1.
