April 2017
2-535
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
117-320 to 117-324, 327, 329, 338, 117-325, 117-326
Status Indicator RAPs
Launch Issue
117-320 to 117-324, 327, 329, 338 SD Card Fail RAP
117-320 When starting, the SD card hardware error was detected by SysCheckSD.
117-321 When starting, the installed SD card was detected to be unsupported by Sys-
CheckSD.
117-322 When starting, SD encryption error was detected by SysCheckSD.
117-323 When starting, SD card file system access error was detected by SysCheckSD.
117-324 When the OS is starting up, the system detected that the SD card is meant for another
product and an error is issued.
117-327 Hardware fault processing of NVRAM area/access on the SD card.
117-329 When starting up, the SD card was detected to be not connected by the OS or Sys-
CheckSD.
117-338 Fault in the connection with SD card is detected by the controller.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Ensure the SD card, PL 3.10 Item 11 is the correct variant for the machine and securely
installed.
2. Switch off, then switch on the machine, GP 10.
3. Ensure that all connectors on the drive PWB, PL 1.10 Item 3 and the ESS PWB, PL 3.10
Item 6 are securely connected. Ensure all surface mounted modules on both PWBs are
securely connected.
4. Reload the software, GP 4.
5. Perform the OF2 Special Boot Modes RAP.
6. If the fault persists, install a new components as necessary:
•SD card, PL 3.10 Item 11.
• ESS PWB, PL 3.10 Item 6.
117-325, 117-326 Access Fail RAP
117-325 Failed to obtain RTC timer value due to hardware problem in the contract function.
117-326 Software fault processing of NVRAM area/access.
Procedure
Switch off, then switch on the machine, GP 10.
To Next Page
