April 2017
2-324
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
024-950, 024-951
Launch Issue
Status Indicator RAPs
024-950 Tray 1 Empty RAP
BSD-ON: BSD 7.7 Tray 1 Paper Stacking
024-950 Tray 1 is empty.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 071-101, tray 1 no paper sensor. Manually actuate the tray 1 no paper sen-
sor, PL 80.10 Item 6. The display changes.
YN
Check the tray 1 no paper sensor. Refer to GP 7 How to Check a Sensor.
Perform the 071-210 Tray 1 Lift Fail RAP. Check the tray 1 feed/lift motor. If the fault persists,
install new components as necessary:
• Tray 1 no paper sensor, PL 80.10 Item 6.
•Drive PWB, PL 1.10 Item 3.
024-951 Tray 2 Empty RAP
BSD-ON: BSD 7.8 Tray 2 Paper Stacking (STM)
BSD-ON: BSD 7.9 Tray 2 Paper Stacking (1TM)
BSD-ON: BSD 7.10 Tray 2 Paper Stacking (3TM)
BSD-ON: BSD 7.19 Tray 2 Paper Stacking (TTM)
024-951 Tray 2 is empty.
Initial Actions
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Switch off, then switch on the machine, GP 10.
Procedure
Enter dC330, code 072-101, tray 2 no paper sensor. Manually actuate the tray 2 no paper sen-
sor, PL 80.20 Item 6. The display changes.
YN
Check the tray 2 no paper sensor. Refer to GP 7 How to Check a Sensor.
Perform the 072-210 Tray 2 Lift Fail RAP. Check the tray 2 feed/lift motor. If the fault persists,
install new components as necessary:
• Tray 2 no paper sensor PL 80.20 Item 6.
•1TM PWB, PL 70.17 Item 5.
•3TM PWB, PL 70.23 Item 5.
• STM PWB, PL 70.28 Item 4.
• TTM PWB, PL 70.90 Item 1.
