Xerox VersaLink B7025 Service Manual

April 2017
2-50
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
005-945, 005-947
Launch Issue
Status Indicator RAPs
005-945, 005-947 Fast Scan Size Mismatch Jam RAP
BSD-ON: BSD 5.5 Document Feeding (2 of 2)
005-945 Fast scan direction (width) size mismatch was detected during CVT no-mix, or CVT
slow scan.
005-947 Fast scan direction (width) size mismatch was detected during CVT no-mix, or CVT
slow scan.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Refer to the procedure that follows as necessary:
• GP 7 How to Check a Sensor.
Perform the steps that follow:
1. Check the size of the document that was fed by the user.
2. Enter dC330. Check the sensors that follow:
• Code 005-218, DADF APS sensor 1,PL 5.50 Item 8.
• Code 005-219, DADF APS sensor 2, PL 5.50 Item 8.
• Code 005-220, DADF APS sensor 3, PL 5.50 Item 8.
3. If the fault persists, install a new DADF PWB, PL 5.10 Item 11.
