Xerox VersaLink B7025 Service Manual

April 2017
2-577
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
132-310, 132-311
Status Indicator RAPs
Launch Issue
132-310, 132-311 UI Software Failure RAP
132-310 UI browser software failure.
132-311 UI contents software failure.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Switch off, then switch on the machine, GP 10.
2. Start the machine in special boot mode LONGDIAG MODE, GP 22.
3. If the fault persists, install a new components as necessary:
• UI assembly, PL 2.05 Item 7.
• UI harness, PL 2.05 Item 3.
• ESS PWB, PL 3.10 Item 6.
4. If the fault persists, reinstall the original components. Obtain a device log, refer to GP 19
Obtaining Audit and Device Logs. Escalate the problem to 2nd Level support.
