April 2017
2-54
Xerox® VersaLink® B7025/B7030/B7035 Multifunction Printer
010-414, 010-418, 420
Launch Issue
Status Indicator RAPs
010-414 Fuser Web Life End RAP
010-414 Fuser web life end.
Procedure
WARNING
Ensure that the electricity to the machine is switched off while performing tasks that do
not need electricity. Refer to GP 10. Disconnect the power cord. Electricity can cause
death or injury. Moving parts can cause injury.
Perform the steps that follow:
1. Install a new fuser, PL 10.05 Item 2.
010-418, 420 Fuser Near Life Warning RAP
BSD-ON: BSD 10.2 Fusing Heat Control (2 of 2)
010-418 Fuser replacement time is approaching.
010-420 Fuser replacement time is approaching.
Procedure
No service action necessary. Advise the customer that the fuser is near of life.
To Next Page
