Install Stratix 5410 Switches Chapter 4
Switch Specifications
For additional specifications and certifications, see the Stratix Ethernet Device
Specifications Technical Data, publication
1783-TD001.
Power Supply Specifications
ATTENTION: Use only a soft dry anti-static cloth to wipe down equipment. Do not use any cleaning agents.
ATTENTION: Electrical Safety Considerations
(Switches with DC power supply modules) To comply with the CE Low Voltage Directive (LVD), all connections to this equipment
must be powered from a source compliant with the following:
• Safety Extra Low Voltage (SELV) Supply
• Protected Extra Low Voltage (PELV) Supply
Attribute 1783-IMS28NDC, 1783-IMS28RDC,
1783-IMS28GNDC, 1783-IMS28GRDC
1783-IMS28NAC, 1783-IMS28RAC,
1783-IMS28GNAC, 1783-IMS28GRAC
Power input 24…60V DC, 10 A 100…240V AC, 50…60 Hz, 2 A (per
slot)
or
100…250V DC, 2 A (per slot)
PoE output 54V DC, 15.4 W, max
PoE+ output 54V DC, 30 W, max
Alarm relay 30V DC, 1 A or 48V DC, 0.5 A
Torque,
power supply mount screw
0.904…1.13 N•m (8…10 lb•in)
Torque, power terminal screw 0.96 N•m (± 0.06 N•m) or 8.5 lb•in (± 0.5 lb•in)
Torque,
functional ground lug screw
3.39 N•m (± 0.23 N•m) or 30 lb•in (± 2 lb•in)
Operating temperature -40 °C<Ta<+60 °C (-40…140 °F)
Attribute 1783-IMXDC 1783-IMXAC
Input 24…60V DC, 10 A 100 …240V AC, 2.0 A
100 …250V DC, 2.0 A
Output -54V DC…2.9 A
4.5V DC, 0.5 A
-54V DC, 2.9 A
4.5V DC, 0.5A
