Allen-Bradley Stratix 5400 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 21
About the Switches Chapter 1
Software Features
Switch software features can be configured via Device Manager, the
Logix Designer application, or both:
•See
Configuration via Device Manager on page 47
•See
Configuration via the Studio 5000 Environment on page 53
All features can be configured via the command-line interface (CLI).
Some features are available only on select switches and expansion modules.
Table 2 - Software Features
Feature Switches Device Manager Logix Designer
Access Control Lists (ACLs) All
•
—
Alarms All
•
—
CIP Sync Time Synchronization/
Precision Time Protocol (PTP)
All Stratix 5400 switches
All Stratix 5410 switches
Stratix 5700 switches: 1783-BMS10CGN, 1783-BMS10CGP, 1783-BMS12T4E2CGNK,
1783-BMS12T4E2CGP, 1783-BMS20CGN, 1783-BMS20CGP, 1783-BMS20CGPK
ArmorStratix 5700 switches: 1783-ZMS4T4E2TGP, 1783-ZMS8T8E2TGP, 1783-ZMS4T4E2TGN,
1783-ZMS8T8E2TGN
All Stratix 8000 and 8300 switch base units (PTP traffic can be only forwarded through
expansion modules)
••
Device-level Ring (DLR) All Stratix 5400 switches
Stratix 5700 switches: 1783-BMS10CGP, 1783-BMS10CGN, 1783-BMS12T4E2CGL,
1783-BMS12T4E2CGP, 1783-BMS12T4E2CGNK,1783-BMS20CL, 1783-BMS20CA,
1783-BMS20CGL, 1783-BMS20CGP, 1783-BMS20CGN, 1783-BMS20CGPK
ArmorStratix 5700 switches: 1783-ZMS4E4T2GP, 1783-ZMS8E8T2GP, 1783-ZMS8E8T2GN,
1783-ZMS8E8T2GN
••
Dynamic Host Configuration Protocol
(DHCP) Persistence
All
••
DHCP for Ring Devices Stratix 5400 switches
Stratix 5700 switches
ArmorStratix 5700 switches
••
Enhanced Interior Gateway Routing
Protocol (EIGRP)
Stratix 5400 switches with Layer 3 firmware
Stratix 5410 switches with Layer 3 firmware
Stratix 8300 base units
• —
EtherChannels All
•
—
Motion Prioritized QoS macros Stratix 5400 switches
Stratix 5410 switches
Stratix 5700 switches with Full firmware
ArmorStratix 5700 switches
•
—
Horizontal stacking Stratix 5410 switches: 1783-IMS28NAC, 1783-IMS28RAC, 1783-IMS28NDC, 1783-IMS28RDC
——
Internet Group Management Protocol
(IGMP) Snooping with Querier
All
• —
Multi-mode Express Setup Stratix 5400 switches
Stratix 5410 switches
Straitx 5700 switches
ArmorStratix 5700 switches
Stratix 8000 switches
Stratix 8300 switches
••
