Allen-Bradley Stratix 5400 User Manual

504 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix C Port Numbering
Stratix 5410 Port Numbering
The port ID consists of the following:
• Port type (Gigabit Ethernet or 10 Gigabit Ethernet)
• Unit number (always 1))
• Port number (1…28)
Gigabit Ethernet is abbreviated as Gi and 10 Gigabit Ethernet as Te.
Table 165 - Stratix 5410 Port Numbering
Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.text File
1783-IMS28NDC 28-port (12 Gigabit PoE/PoE+ ports; 12 Gigabit+ 4 10 Gigabit SFP ports)
managed switch; Layer 2 firmware; DC power supply
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
Gi1/1
Gi1/2
Gi1/3
Gi1/4
Gi1/5
Gi1/6
Gi1/7
Gi1/8
Gi1/9
Gi1/10
Gi1/11
Gi1/12
Gi1/13
Gi1/14
Gi1/15
Gi1/16
Gi1/17
Gi1/18
Gi1/19
Gi1/20
Gi1/21
Gi1/22
Gi1/23
Gi1/24
Te1/25 or Gi1/25
Te1/26 or Gi1/26
Te1/27 or Gi1/27
Te1/28 or Gi1/28
1783-IMS28NAC 28-port (12 Gigabit PoE/PoE+ ports; 12 Gigabit+ 4 10 Gigabit SFP ports)
managed switch; Layer 2 firmware; AC power supply
1783-IMS28RDC 28-port (12 Gigabit PoE/PoE+ ports; 12 Gigabit+ 4 10 Gigabit SFP ports)
managed switch; Layer 3 firmware; DC power supply
1783-IMS28RAC 28-port (12 Gigabit PoE/PoE+ ports; 12 Gigabit+ 4 10 Gigabit SFP ports)
managed switch; Layer 3 firmware; AC power supply
1783-IMS28GNDC 28-port (12 Gigabit PoE/PoE+ ports; 16 Gigabit SFP ports) managed
switch; Layer 2 firmware; DC power supply
1783-IMS28GNAC 28-port (12 Gigabit PoE/PoE+ ports; 16 Gigabit SFP ports) managed
switch; Layer 2 firmware; AC power supply
1783-IMS28GRDC 28-port (12 Gigabit PoE/PoE+ ports; 16 Gigabit SFP ports) managed
switch; Layer 3 firmware; DC power supply
1783-IMS28GRAC 28-port (12 Gigabit PoE/PoE+ ports; 16 Gigabit SFP ports) managed
switch; Layer 3 firmware; AC power supply
