Allen-Bradley Stratix 5400 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 515
Port Numbering Appendix C
Stratix 8000 and 8300
Port Numbering
The port ID consists of the following:
• Port type (Gigabit Ethernet for Gigabit ports and Fast Ethernet for
10/100 Mbps ports)
• Unit number (1, 2, or 3)
• Port number (1…2 for Gigabits, 1…4 for the 6-port base and 1…8 for all
others)
Gigabit Ethernet is abbreviated as Gi and Fast Ethernet as Fa.
For the expansion modules, the Fa# represents slot 2 o 3.
Table 168 - Stratix 8000/8300 Switch and Expansion Module Port Numbering
Cat. No. Description Port Numbering on Switch Labels Port Numbering in config.txt Text File
1783-MS06T 6-port (2 Gigabit ports; 4 Ethernet ports) base switch Gigabit ports:
1
2
Fast Ethernet ports:
1
2
3
4
Gigabit ports:
Gi1/1
Gi1/2
Fast Ethernet ports:
Fa1/1
Fa1/2
Fa1/3
Fa1/4
1783-MS10T 10-port (2 Gigabit ports; 8 Ethernet ports) base switch Gigabit ports:
1
2
Fast Ethernet ports:
1
2
3
4
5
6
7
8
Gigabit ports:
Gi1/1
Gi1/2
Fast Ethernet ports:
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
1783-RMS06T 6-port (2 Gigabit ports; 4 Ethernet ports) base switch Gigabit ports:
1
2
Fast Ethernet ports:
1
2
3
4
Gigabit ports:
Gi1/1
Gi1/2
Fast Ethernet ports:
Fa1/1
Fa1/2
Fa1/3
Fa1/4
1783-RMS10T 10-port (2 Gigabit ports; 8 Ethernet ports) base switch Gigabit ports:
1
2
Fast Ethernet ports:
1
2
3
4
5
6
7
8
Gigabit ports:
Gi1/1
Gi1/2
Fast Ethernet ports:
Fa1/1
Fa1/2
Fa1/3
Fa1/4
Fa1/5
Fa1/6
Fa1/7
Fa1/8
