Allen-Bradley Stratix 5400 User Manual

Rockwell Automation Publication 1783-UM007G-EN-P - February 2017 455
Data Types Appendix A
6-port Switches
Catalog numbers 1783-BMS06SL, 1783-BMS06SA, 1783-BMS06TL,
1783-BMS06TA
PortGi1_2Utilization SINT Decimal
MajorAlarmRelay BOOL Decimal AlarmRelay:0
MulticastGroupsActive DINT Binary
Table 138 - Output Data Type (6-port Gb switches)
AB:STRATIX_5700_6PORT_GB_MANAGED:O:0
Member Name Type Default Display
Style
Valid Values
AllPortsDisabled BOOL Decimal DisablePort:0
PortFa1_1Disable BOOL Decimal DisablePort:1
PortFa1_2Disable BOOL Decimal DisablePort:2
PortFa1_3Disable BOOL Decimal DisablePort:3
PortFa1_4Disable BOOL Decimal DisablePort:4
PortGi1_1Disable BOOL Decimal DisablePort:5
PortGi1_2Disable BOOL Decimal DisablePort:6
Table 139 - Input Data Type (6-port switches)
AB:STRATIX_5700_6PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortFa1_5UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
Table 137 - Input Data Types (6-port Gb switches) (continued)
AB:STRATIX_5700_6PORT_GB_MANAGED:I:O
Member Name Type Default Display
Style
Valid Values
