38 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 2 Get Started
Single-mode Express Setup
To run single-mode Express Setup, follow these steps.
1. Make sure that at least one switch Ethernet port is available for Express
Setup.
2. Apply power to the switch.
When the switch powers on, it begins its power-on sequence. The
power-on sequence can take up to 90 seconds to complete.
3. Make sure that the power-on sequence has completed by verifying that
the EIP Mod and Setup status indicators are flashing green.
If the switch fails the power-on sequence, the EIP Mod status indicator
turns red.
4. Press and release the Express Setup button.
Unlike multi-mode Express Setup, there is no time requirement for
when you release the Express Setup button.
5. Wait a few seconds until the status indicator on one of the unconnected
switch ports flashes green.
6. Connect a Category 5 Ethernet cable from the flashing switch port to
the Ethernet port on a computer.
or
For 1783-BMS4S2SGL or 1783-BMS4S2SGA switches, do one of the
following:
• Insert a copper SFP module into the Gi1/1 port on the switch. Then
connect a Category 5 Ethernet cable from the SFP module to the
Ethernet port on the computer.
• Connect the Gi1/1 port on the switch to the Ethernet port on the
computer by using a fiber-to-Ethernet media converter.
7. Proceed to
Configure Network Settings via Device Manager on page 39.
IMPORTANT Port Gi1/1 does not flash during setup, but must be used to connect
1783-BMS4S2SGL or 1783-BMS4S2SGA switches to a computer.
IMPORTANT If you wait too long to connect the cable, the Setup status indicator
turns off.
