Allen-Bradley Stratix 5400 User Manual

130 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 5 Install Stratix 5700 Switches
Specifications
For additional specifications and certifications, see the Stratix Ethernet Device
Specifications Technical Data, publication
1783-TD001.
Overview
When determining where to place the switch, observe these guidelines:
• For 10/100 ports and 10/100/1000 ports, the cable length from a
switch to an attached device cannot exceed 100 m (328 ft).
• The fiber-optic cable length from a switch to an attached device cannot
exceed the distance that is specified in Appendix
D.
• For maximum noise immunity, shielded cables must be used on the
RJ45 uplink ports (Gi1/1 and Gi1/2) on these switches:
Table 25 - Stratix 5700 Switches
Attribute 1783-BMS4S2SGL, 1783-BMS4S2SGA, 1783-BMS06SL, 1783-BMS06SA,
1783-BMS06TL, 1783-BMS06TA, 1783-BMS06SGL, 1783-BMS06SGA,
1783-BMS06TGL, 1783-BMS06TGA, 1783-BMS10CL, 1783-BMS10CA,
1783-BMS10CGL, 1783-BMS10CGA,1783-BMS10CGP, 1783-BMS10CGN
1783-BMS20CL, 1783-BMS20CA, 1783-BMS20CGL, 1783-BMS20CGP,
1783-BMS20CGPK, 1783-BMS20CGN
Wire size, power connectors
0.5…0.8 mm
2
(18…20 AWG) twisted-pair copper wire suitable for 30 °C (86 °F) above surrounding ambient temperature outside of the enclosure
Screw torque, ground terminals 0.4 N•m (3.5 lb•in)
Screw torque, power terminals 0.23 N•m (2.0 lb•in)
Alarm relay ratings 30V DC, 1.0 A or 48V DC, 0.5 A
Power supply 12…48V DC, 0.5 … 2.0 A max 12…48V DC, 0.5 …3.0 A max
Table 26 - Stratix 5700 Power over Ethernet Switches
Attribute 1783-BMS12T4E2CGL, 1783-BMS12T4E2CGP, 1783-BMS12T4E2CGNK
Wire size, power connectors
0.5…0.8 mm
2
(18…20 AWG) twisted-pair copper wire suitable for 30 °C (86 °F) above surrounding ambient temperature outside of the enclosure
Screw torque, ground terminals 0.4 N•m (3.5 lb•in)
Screw torque, power terminals 0.23 N•m (2.0 lb•in)
Alarm relay ratings 30V DC, 1.0 A or 48V DC, 0.5 A
Switch power input 12…48V DC, 0.5…3.0 A max
PoE power input Application
PoE only (IEEE 802.3af)
PoE and PoE+ (IEEE 802.3at Type 2)
Power Consumption
44…57V DC (48V DC nom)
50…57V DC (54V DC nom)
Power Supply per Port
15.4 W, max for PoE
30 W, max for PoE+
• 1783-BMS06TGL
• 1783-BMS06TGA
• 1783-BMS10CGL
• 1783-BMS10CGA
• 1783-BMS10CGN
• 1783-BMS10CGP
• 1783-BMS12T4E2CGNK
• 1783-BMS12T4E2CGP
• 1783-BMS12T4E2CGL
• 1783-BMS20CGL
• 1783-BMS20CGN
• 1783-BMS20CGP
• 1783-BMS20CGPK
