102 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Chapter 4 Install Stratix 5410 Switches
Overview
When determining where to place the switch, observe these guidelines:
• Airflow around the switch is unrestricted. To prevent the switch from
overheating, observe these minimum clearances:
– Top and bottom: 44.45 mm (1.75 in.)
– Sides: 50.8 mm (2.0 in.)
– Front: 50.8 mm (2.0 in.)
• For 10/100/1000 Ethernet, PoE/PoE+ ports, the cable length from a
switch to an attached device cannot exceed 100 m (328 ft).
• The fiber-optic cable length from a switch to an attached device cannot
exceed the distance that is specified in Appendix
D.
• Temperature surrounding the unit must be in a range of -40…60 °C
(-40…140 °F).
• Clearance to front and rear panels meets these conditions:
– Front- or back-panel status indicators can be easily read.
– Access to ports is sufficient for unrestricted cabling.
– Power and alarm relay connectors are within reach of the connection
to the AC or DC power source.
• Cabling is away from sources of electrical noise, such as radios, power
lines, and fluorescent lighting fixtures.
ATTENTION: Do not wire more than 1 conductor on any single terminal.
