454 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
Stratix 5700 and
ArmorStratix 5700
Data Types
The following tables list module-defined data types for Stratix 5700 and
ArmorStratix 5700 switches. The tables include information for input (I) and
output (O).
6-port Gb Switches
Catalog numbers 1783-BMS4S2SGL, 1783-BMS4S2SGA,1783-BMS06SGL,
1783-BM06SGA, 1783-BMS06TGL, 1783-BMS06TGA
Table 137 - Input Data Types (6-port Gb switches)
AB:STRATIX_5700_6PORT_GB_MANAGED:I:O
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortGi1_1Connected BOOL Decimal LinkStatus:5
PortGi1_2Connected BOOL Decimal LinkStatus:6
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
PortFa1_4UnauthorizedDevice BOOL Decimal UnauthorizedDevice:4
PortGi1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:5
PortGi1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:6
AnyPortThreshold BOOL Decimal ThresholdExceeded:0
PortFa1_1Threshold BOOL Decimal ThresholdExceeded:1
PortFa1_2Threshold BOOL Decimal ThresholdExceeded:2
PortFa1_3Threshold BOOL Decimal ThresholdExceeded:3
PortFa1_4Threshold BOOL Decimal ThresholdExceeded:4
PortGi1_1Threshold BOOL Decimal ThresholdExceeded:5
PortGi1_2Threshold BOOL Decimal ThresholdExceeded:6
AllPortsUtilization SINT Decimal
PortFa1_1Utilization SINT Decimal
PortFa1_2Utilization SINT Decimal
PortFa1_3Utilization SINT Decimal
PortFa1_4Utilization SINT Decimal
PortGi1_1Utilization SINT Decimal
