Allen-Bradley Stratix 5400 User Manual

474 Rockwell Automation Publication 1783-UM007G-EN-P - February 2017
Appendix A Data Types
20-port Switches
Catalog numbers 1783-BMS20CL, 1783-BMS20CA
PortFa1_18Disable BOOL Decimal DisablePort:18
PortGi1_1Disable BOOL Decimal DisablePort:19
PortGi1_2Disable BOOL Decimal DisablePort:20
Table 154 - Input Data Type (20-port switches)
AB:STRATIX_5700_20PORT_MANAGED:I:0
Member Name Type Default Display
Style
Valid Values
Fault DINT Binary
AnyPortConnected BOOL Decimal LinkStatus:0
PortFa1_1Connected BOOL Decimal LinkStatus:1
PortFa1_2Connected BOOL Decimal LinkStatus:2
PortFa1_3Connected BOOL Decimal LinkStatus:3
PortFa1_4Connected BOOL Decimal LinkStatus:4
PortFa1_5Connected BOOL Decimal LinkStatus:5
PortFa1_6Connected BOOL Decimal LinkStatus:6
PortFa1_7Connected BOOL Decimal LinkStatus:7
PortFa1_8Connected BOOL Decimal LinkStatus:8
PortFa1_9Connected BOOL Decimal LinkStatus:9
PortFa1_10Connected BOOL Decimal LinkStatus:10
PortFa1_11Connected BOOL Decimal LinkStatus:11
PortFa1_12Connected BOOL Decimal LinkStatus:12
PortFa1_13Connected BOOL Decimal LinkStatus:13
PortFa1_14Connected BOOL Decimal LinkStatus:14
PortFa1_15Connected BOOL Decimal LinkStatus:15
PortFa1_16Connected BOOL Decimal LinkStatus:16
PortFa1_17Connected BOOL Decimal LinkStatus:17
PortFa1_18Connected BOOL Decimal LinkStatus:18
PortFa1_19Connected BOOL Decimal LinkStatus:19
PortFa1_20Connected BOOL Decimal LinkStatus:20
AnyPortUnauthorizedDevice BOOL Decimal UnauthorizedDevice:0
PortFa1_1UnauthorizedDevice BOOL Decimal UnauthorizedDevice:1
PortFa1_2UnauthorizedDevice BOOL Decimal UnauthorizedDevice:2
PortFa1_3UnauthorizedDevice BOOL Decimal UnauthorizedDevice:3
Table 153 - Output Data Type (20-port Gb switches) (continued)
AB:STRATIX_5700_20PORT_GB_MANAGED:O:0
Member Name Type Default
Display Style
Valid Values
